Coolwell 30KG Serial Bus Servo, High Precision and Switchable Torque,Servo/Motor Mode, Programmable 360 Degrees Magnetic Encoder

Description

• 360 Magnetic Encoder; High Precision, Longer Lifetime
• UART Serial Bus Control: Allows Controlling Up To 253 Serial Bus Servos At The Same Time
• Large Torque: Up To 30kg.Cm Torque On 12V Voltage, Suitable For Building Quadruped Robots, Hexapod Walkers, Robotic Arms And Other Robotic Projects Requiring Multiple Servos
• Acceleration Start-Stop Function: The Speed And Acceleration Values Can Be Set, And The Motion Effect Is Softer
• Up to 253 servos can be connected in series at the same time (requires full power), also can obtain feedback information from each servo.

Feature

360magnetic encoder, larger angle control range.
High precision, the angle control accuracy reaches 360/4096.
Any angles can be set as the middle of the position, which is convenient for assembly.
Acceleration start and stop function, the movement effect is softer.
Compact structure design and the product appearance is more beautiful.
6-12.6V Wide-voltage input, it can directly supply power with 2s or 3s lithium battery.
High torque, up to 30kg.cm@12V.
The working mode can be set by the program: servo angle control/motor model can be rotated continuously.
Up to 253 servos can be connected in series at the same time (requires full power), also can obtain feedback information from each servo.

Application

Servos will provide various feedback like position, speed, torque lock, operating mode (servo mode, servo motor mode, etc.)
for advanced projects requiring closed-loop automatic control.
Ideal choice for building quadruped robots, hexapod walkers, robotic arms and other robotic projects requiring multiple
servos. (This product provides the open source model of the quadruped robots as shown in the picture below.)

Package includes

1. ST3215 Servo x1

Resources download: https://www.waveshare.com/wiki/ST3215_Servo
