VIFLY 1S Series Charging Board, Storage Charge and Discharge 1S LiPo Batteries with Standard Charger, PH2.0 and BT2.0 Compatible

Description

• Storage charge and discharge1S LiPo batteries with standard charger.
• Charge 1-6 1S batteries at the same time.
• Turn the knob for the number of batteries you are charging.
• The added fuse makes the board even safer.
• Pre-soldered PH2.0 and BT2.0 connectors.

Features:
1. Storage charge and discharge 1S LiPo batteries with standard charger.
2. Charge 1-6 1S lipo batteries at the same time.
3. Turn the knob for the number of batteries you are charging.
4. The added fuse makes the board even safer.
5. Pre-soldered PH2.0 and BT2.0 connectors.
Operation:
Firstly, turn the knob to the corresponding position according to the battery quantity you will charge, then plug-in the batteries in sequence 1S-2S-3S, finally connect the series board to the charger with cables.
Example: You have 3 whoop batteries to charge, firstly turn the knob to 3S position, then plug the battery into port 1S, 2S and 3S in sequence, and finally connect it to the charger with the balance cable and XT60 cable.
Warning:
1. It is series board not parallel board. For example, when you are charging 4pcs 300mAh lipos, set your charger to 0.3A for 1C or 0.6A for 2C. NOT 1.2A or 2.4A.
2. The specs of all batteries should be the same, ie, battery capacity, battery type, brand, etc.
3. Never leave the board unattended while charging or discharging.
4. Do not charge over 1.5amps. The fuse is 5A that not means you can charge it in 5A, the knob is rated for 1.5A so don't charge it over 1.5A.
5. Don't plug in both PH2.0 and BT2.0 battery in the same port.
Specs:
Dimensions : 73*39*33mm
Weight :49g
Battery type : PH2.0 & BT2.0
Max charging current : 1.5A
Working Voltage: Less than 30V
